In modern laboratories, centrifuges are widely used as basic equipment in fields such as biology, chemistry, medicine, and food testing. Especially in laboratories that require handling large capacity samples, the use of ultra large capacity centrifuges is crucial. To meet the needs of scientific research and production, Changsha Shi Ge Yan Biotechnology Co., Ltd. has launched the 7S floor standing ultra large capacity centrifuge, which has high efficiency, stability, and intelligent operation. It is an ideal choice for fields such as scientific research, pharmaceuticals, clinical testing, and food safety testing.
Equipped with a high torque brushless variable frequency motor, imported fluorine free compressor unit, intelligent microcomputer control system, and precise temperature control system, the 7S floor standing ultra large capacity centrifuge not only has excellent performance, but also has extremely high cost-effectiveness, especially suitable for experiments that require high centrifugal force and temperature control. Combined with a three year warranty, replacement only, no repair, Changsha Shi Ge Yan also provides strong support for users in terms of equipment quality and service assurance.
Maintenance free: The 7S floor standing ultra large capacity centrifuge adopts a high torque brushless variable frequency motor, which has the advantages of no dust and maintenance free. It not only improves the working efficiency of the motor, but also extends the service life of the equipment.
Fast up and down speed: This motor system supports fast up and down speed, ensuring that the set speed can be reached in a short time during the experiment, reducing the waiting time for the experiment.
Low noise and vibration: Due to the more stable operation of the motor, the equipment has less vibration and noise during operation, ensuring a quiet laboratory environment.
Precise speed control: By directly driving the rotor through a flexible shaft drive system, the motor can be effectively protected while ensuring precise speed control and stable centrifugal force during the centrifugation process.
Smooth operation: This drive system can ensure the smoothness of the operation process, greatly reducing the impact of vibration on experimental results.
Protecting the motor: The design of the flexible shaft not only improves the durability of the motor, but also effectively reduces wear and tear, thereby reducing the possibility of equipment failure.
Safety design: The equipment is equipped with an induction automatic electric suction door lock and an emergency door opening device. This means that when the equipment exceeds the speed, temperature, or is unbalanced, the system will automatically lock the door cover to ensure the safety of the experimenters.
Self check and protection functions: including multiple safety self check functions such as door lock protection, overspeed, overtemperature, imbalance, etc., to ensure that the equipment will not have any safety hazards during operation.
Efficient refrigeration: The equipment adopts imported customized fluorine free compressor units, combined with high-quality copper pipes and full tin technology, which can reduce the centrifugal chamber temperature from room temperature 25 ℃ to 4 ℃ in just 4 minutes, ensuring the stability of temperature sensitive samples.
Dual electronic valve temperature control: This system controls the temperature through dual electronic valves, further improving the refrigeration efficiency and ensuring the temperature control accuracy of the equipment during long-term operation.
Automatic constant temperature control system: The precise constant temperature control system makes the temperature more stable, especially in high-throughput experiments, where the equipment can always maintain optimal working conditions.
Intelligent system: The device is precisely controlled by a microcomputer processor, equipped with a high-definition touch screen, and supports intelligent operation. The operator can directly set parameters such as speed, time, temperature, etc. through the touch screen, making the operation simple and fast.
Display function: The display interface can not only show the speed, running time, temperature, but also real-time display of the currently selected rotor specifications, maximum speed, maximum centrifugal force, door cover switch status, real-time date and time, etc.
User friendly design: The touch screen design supports wearing latex gloves for operation, without direct contact with the screen, improving the convenience and hygiene of laboratory operations.
Fully automatic lifting door: equipped with one key switch, door closing function, and anti pinch function.
Power outage emergency door opening function: Even in the event of a power outage, the device can be easily opened through the emergency door opening function without relying on UPS power supply.
Centrifugal chamber door integrated lifting: The optional centrifugal chamber door integrated lifting function does not require manual operation, further improving the efficiency of laboratory operations.
Central computer control and monitoring: It has programmatic operation and supports central computer control and monitoring functions, providing support for centralized management of large laboratories.
Maximum speed: 8000 r/min
Maximum centrifugal force: 14551 × g
Maximum capacity: 6 × 2400 ml horizontal rotor
Temperature control range: -20 ℃~40 ℃
Timing range: 1 min~9 h 59 min
Noise: ≤ 68 dBA
Dimensions: 940 × 890 × 1010 mm
Net weight: 600 kg
Speed control accuracy: ± 10 r/min
Power supply: AC 380/220V, 50HZ
Temperature control accuracy: ± 1 ℃
Packaging: Wooden crate 1200 × 1050 × 1565mm
The 7S floor standing ultra large capacity centrifuge supports multiple rotor configurations, and users can choose the appropriate rotor according to their experimental needs. Common adapted rotors include:
Horizontal rotor: supports sample capacities of up to 6 × 2400 ml and 6 × 2000 ml, suitable for separating large capacity samples.
Angular rotor: The speed can reach up to 8000 r/min, suitable for high-speed centrifugation of small capacity samples.
The rotors equipped with the 7S floor standing ultra large capacity centrifuge are all cast in one piece, which has the characteristics of high strength, strong corrosion resistance, and high space utilization. The surface of the rotor has been polished and treated with PTFE to ensure that the equipment is not easily corroded after long-term use.
Suitable for the separation of small particles such as proteins, enzymes, viral particles, organelles, etc., widely used in basic research such as genomics and cytology.
The 7S centrifuge is commonly used for blood separation, cell precipitation, and the separation and processing of other medical samples, suitable for various clinical tests.
Used for drug development, protein purification, vaccine research, etc., it is of great significance for the processing of drug molecules and biological samples.
The 7S centrifuge can be used for component separation in food and analysis of environmental pollutants, ensuring the accuracy of experimental results.
The three-year warranty policy provided by Changsha Shi Ge Yan ensures that users can receive free equipment replacement or repair services during the warranty period.
During the warranty period, if the equipment malfunctions, Changsha Shi Ge Yan promises to only replace it without repairing it, greatly reducing the risk of downtime and high maintenance costs caused by equipment repairs.
Provide customers with nationwide free shipping services and offer legitimate invoices to ensure a transparent and reliable procurement process.
The 7S floor standing ultra large capacity centrifuge has become an important experimental equipment in scientific research, medicine, pharmaceuticals and other fields due to its high performance, precise temperature control, intelligent control and safety design. The equipment provided by Changsha Shi Ge Yan Biotechnology Co., Ltd. comes with a three-year warranty and a service commitment of only replacement and no repair, making it highly competitive in the market.
For users who pursue high performance and low maintenance costs, choosing Changsha Shi Ge Yan's 7S floor standing ultra large capacity centrifuge will effectively improve the laboratory's work efficiency and equipment reliability.
