Centrifuge

Introduction to desktop low-speed centrifuge

Overview

Low speed centrifuge is a high-precision experimental equipment widely used in laboratory fields such as biochemistry, medicine, environmental science, and food inspection. It separates substances of different densities by utilizing the centrifugal force generated by high-speed rotation, and is an indispensable tool in modern laboratories. The 5E desktop low-speed centrifuge produced by Changsha Shi Ge Yan Instrument Manufacturing Co., Ltd. adopts advanced technology and high-quality materials, and has the advantages of high efficiency, stability, and safety, making it particularly suitable for use in various laboratories.

Main Features

High torque brushless motor

The 5E desktop low-speed centrifuge adopts a high torque brushless motor with maintenance free design, which not only reduces the frequency of motor maintenance, but also avoids dust pollution caused by carbon brush motors. The motor has fast acceleration and deceleration, which can quickly reach the set speed and improve experimental efficiency.

safety design

The instrument is equipped with an advanced induction electronic door lock system. The door lock has self checking and protection functions such as emergency door opening device, door lock detection, overspeed, and imbalance, ensuring the safety of the equipment during operation. Even in the event of abnormal situations, the equipment can stop running in a timely manner, protecting the operator and experimental samples.

intelligence control system

5E is equipped with a microcomputer processor for precise control and operated through the "intelligent system" version of the high-definition touch screen. Users can intuitively view key information such as speed, running time, temperature, and speed adjustment gear. In addition, the screen also displays information such as the specifications and models of the currently selected rotor, maximum speed and centrifugal force, door cover opening and closing status, and real-time date and time, making the operation simple and convenient.

Program storage and flexibility

The 5E desktop low-speed centrifuge supports storing and calling 100 commonly used programs to meet different experimental needs. In addition, it offers 9 acceleration rates and 10 deceleration rates for users to choose from, in order to achieve the best centrifugal effect.

All steel structure and explosion-proof design

The machine adopts an all steel structure and a 304 stainless steel centrifugal chamber, with multi-layer explosion-proof design to ensure the stability and safety of the equipment during high-intensity centrifugal operations. In addition, the centrifuge is equipped with a three-stage vibration reduction system and automatic balancing function, further improving the stability and reliability of the equipment.

save space

The 5E desktop low-speed centrifuge has a compact design and small footprint, making it suitable for various laboratories, especially those with limited space. The low opening design makes it more suitable for experimental tables with shelves.

Multiple adapters and rotors

The 5E centrifuge is equipped with multiple rotors and can customize various adapters according to the needs of different experiments, making it versatile and greatly improving the flexibility of instrument use.

Technical Specifications

Maximum speed: 5000 r/min

Maximum relative centrifugal force: 4420 × g

Maximum capacity: 4 × 100 ml

Power supply (V/Hz): AC220V 50HZ 5A

Timing range: 1s-99min

Dimensions: 530 × 370 × 290 mm

Net weight: 33 kg

Noise: ≤ 60 dB (A)

Temperature control accuracy: ± 1 ℃

Speed control accuracy: ± 10 r/min

RPM/RCF conversion: Yes

Certificate: CE, ISO certification for adapter rotary head

The 5E desktop low-speed centrifuge offers a variety of rotor options to meet different experimental needs. The parameters for each rotary head are as follows:

Number rotor type, maximum speed (r/min), maximum capacity (ml), maximum centrifugal force (x g), remarks

NO 05629 horizontal rotor (multi tube frame) 50004 × 1 × 50ml4420 selection

NO 05630 horizontal rotor (4 × 1 × 100ml) 50004 × 1 × 100ml, 4420 to choose from

NO 05634 horizontal rotor (4 × 2 × 50ml) 40004 × 2 × 50ml 2820 to choose from

NO 05633 horizontal rotor (4 × 4 × 15ml) 40004 × 4 × 15ml 2820 purchase

NO 05632 horizontal rotor (4 × 6 × 10ml) 40004 × 6 × 10ml 2580 to choose from

NO 05137 low-speed angle rotor (6 × 15ml) 50006 × 15ml 2540 to choose from

NO 05139 low-speed angle rotor (12 × 15ml) 500012 × 15ml 3080 to choose from

NO 05140 low-speed angle rotor (24 × 15ml) 500024 × 15ml 3500 to choose from

NO 05141 low-speed angle rotor (30 × 15ml) 500030 × 15ml 3830 to choose from

NO 05142 low-speed angle rotor (4 × 50ml) 50004 × 50ml 2520 to choose from

NO 05143 low-speed angle rotor (6 × 50ml) 50006 × 50ml 2850 to choose from

NO 05144 low-speed angle rotor (12 × 50ml) 500012 × 50ml 3860 to choose from

NO 05146 low-speed angle rotor (4 × 100ml) 50004 × 100ml 2630 to choose from

NO 05147 low-speed angle rotor (6 × 100ml) 50006 × 100ml 3130 to choose from

NO 05648 enzyme-linked immunosorbent assay plate rotor 40002 × 2 × 96 well 2020 selection

Warranty and after-sales service

Changsha Shide Testing Instrument Manufacturing Co., Ltd. provides a three-year warranty period for the 5E desktop low-speed centrifuge. During the warranty period, if the equipment malfunctions, the company only provides replacement services without repair to ensure the efficient operation of the instrument. After the warranty period, users can enjoy long-term technical support and maintenance services to ensure the continuous use of the equipment.

Conclusion

The 5E desktop low-speed centrifuge has become a commonly used centrifugal separation equipment in laboratories due to its advanced technology, high safety, and flexible operating interface. It is suitable for laboratories of different scales, can meet various centrifugation needs, and can flexibly respond to different experimental sample processing through the selection of multiple rotors and adapters. In addition, the high-quality after-sales service provided by Changsha Shi Yi Yan Instrument Manufacturing Co., Ltd. makes this instrument an ideal choice in the laboratory.
